QHY5III568C (Color)

Write a review
Hubungi Kami untuk Harga
Ask a question
In stock

QHY5III568C is a back-illuminated planetary & guiding camera of the latest 5III V2 series. It utilizes a global shutter, and supports true hardware binning. It can reach a super-high speed at about 304fps with nearly 1080p resolution.

The QHY5III568M/C inherits all of the updates and improvements of the QHY5III Series Ver. 2 line of cameras.

Spesification:

  • Model: QHY5III568C
  • CMOS Sensor: Sony IMX568
  • Pixel Size: 2.74um*2.74um
  • Effective Pixel Area: 2472*2064
  • Effective Pixels: 5.1 Mega Pixel
  • Fullwell Full Resolution: 8.8ke-2X2 FD Binning: 9.7ke-
  • Readout Noise Full Resolution: 1.5-2.3e-2X2 FD Binning: 1.6-2.7e-
  • AD Sample Depth: 12-bit (output as 16-bit and 8-bit)
  • Built-in Image Buffer: 512MB DDR3 Memory
  • Full Resolution Frame Rate: 2472X2064 @8Bit 64.9FPS @16Bit 34.5Fps
  • ROI Frame Rate: 1920X1080 @8Bit 115.6Fps @16Bit 62.1Fps ; 800X600 @8Bit 187.2Fps @16Bit 100.5Fps ; 480X480 @8Bit 221.2Fps @16Bit 118.5Fps 2X2 FD Binning; 1236X1032 @8Bit 304Fps @16Bit 152Fps; 800X600 @8Bit 439.6Fps @16Bit 221.9Fps; 480X480 @8Bit 519.6Fps @16Bit 262.8Fps
  • Exposure Time Range: 11us-900sec
  • Shutter Type: Global Shutter
  • Computer Interface: USB3.2 Gen1 Type-C
  • Guide Port: st4
  • Telescope Interface: 1.25-inch, compatible with CS-port and C-port lenses by replacing the front-end connector
  • Front end: AR anti-reflection glass (5III568M) IR-Cut filter (5III568C
  • Back Focal Length: 17mm(with adapter);8±0.5mm(without adapter)
  • Chip package size: 6.7mm*5.6mm(Type1/1.8)
  • Debayer: RGGB
  • Weight: 80g
